HBTS80R
HBTS80R
Item （项目） | Unit | HBTS-80R |
Max. Theoretical Concrete Output | m³/h | 80 |
Max. Concrete Pumping Pressure | Mpa | 16 |
Distribution valve | S Valve | |
Conveying tube inner Dim（输送管内径） | mm | Φ125A |
Max. Theoretical Conveying Distance (Horizontal Distance/Perpendicular Height)（理论输送距离 （水平/垂直 ） | m | 800/150 |
Concrete Cylinder Diameter（混凝土缸直径） | mm | 200*1650 |
Maximum aggregate size（骨料尺寸 ） | mm | 40 |
Concrete slump range（混凝土坍落度 ） | mm | 120-230 |
Diesel model（柴油机型号） | - | 潍柴 |
Power（功率） | kw | 145kw |
Fuel tank capacity（油箱容量） | L | 500 |
Cleaning method(管道清洗方式) | High pressure washing | |
Dimension（尺寸） | mm | 6200*2100*2250 |
Total Weight （重量） | kg | 6200 |
